02.05 9 SIMOSTEP specifications
© Siemens AG 1998 All Rights Reserved
FM-STEPDRIVE/SIMOSTEP (FB)
9-3
Dimension drawings for motors without brake
30
d h6
L
70
85
22.6
6.
5
10
73 h8
2
-1
+ 0.7
70
85
Motor type
SIMOSTEP 1FL3041 110 12
SIMOSTEP 1FL3042 140 12
SIMOSTEP 1FL3043 170 14
d [mm] Order number
1FL3041-0AC31-0BK0
1FL3042-0AC31-0BK0
1FL3043-0AC31-0BG0
L [mm]
Figure 9-1 SIMOSTEP 1FL3041, 1FL3042, 1FL3043 dimension drawings (for motors without brake)
Order number
1FL3061-0AC31-0BG0
1FL3062-0AC31-0BG0
Feather key
A6 x 6 x 25, DIN 6885
19 j6
40 ± 0.3
L ± 1
13
56 h7
3 ± 1
25.6
9
110
89
89
110
Motor type L [mm]
SIMOSTEP 1FL3061 180
SIMOSTEP 1FL3062 228
Figure 9-2 SIMOSTEP 1FL3061, 1FL3062 dimension drawings (for motors without brake)
