9 SIMOSTEP specifications 02.05
© Siemens AG 1998 All Rights Reserved
9-4 FM-STEPDRIVE/SIMOSTEP (FB)
Dimension drawings for motors with brake
d h6
L
30
46.5
22.6
10
73 h8
2
-1
+ 0.7
70
85
6.5
83.5
85
Motor type
SIMOSTEP 1FL3041 110 12
SIMOSTEP 1FL3042 140 12
SIMOSTEP 1FL3043 170 14
d [mm] Order number
1FL3041-0AC31-0BJ0
1FL3042-0AC31-0BJ0
1FL3043-0AC31-0BH0
L [mm]
Figure 9-3 SIMOSTEP 1FL3041, 1FL3042, 1FL3043 dimension drawings (for motors with brake)
52.7
103
Order number
1FL3061-0AC31-0BH0
1FL3062-0AC31-0BH0
19 j6
40 ± 0.3
L ± 1
13
56 h7
3 ± 1
25.6
9
110
89
89
110
Motor type L [mm]
SIMOSTEP 1FL3061 180
SIMOSTEP 1FL3062 228
Figure 9-4 SIMOSTEP 1FL3061, 1FL3062 dimension drawings (for motors with brake)
