Siemens SIMOTICS 1FT2104-4AF - 9 Assembly Drawings;Dimension Sheets; Dimension Drawing 1 FT2, Shaft Height 40

1FT2 synchronous motors for SINAMICS S120
Configuration Manual, 03/2021, A5E50645584B AA
127
Assembly drawings/dimension sheets
9
9.1 Dimension drawing 1FT2, shaft height 40
All dimensions are in mm.
①
Option with shaft sealing ring (IP65 and IP67)
②
Option shaft with feather key
SIMOTICS S-1FT2
Shaft height 40
Motor length
Shaft extension
Without
brake
With
brake
Shaft ∅19 x 40 Shaft ∅14 x 30
(for IP64 and plain
shaft)
DIN
k
k1
d
l
d
l
IEC
LB
LB1
D
L
D
L
1FT2104-4
98
142
19 (k6)
40
14 (k6)
30
1FT2☐04-5
126
170
1FT2☐04-6
144
188
