Siemens SIMOTICS 1FT2104-4AF - Dimension Drawing 1 FT2, Shaft Height 48

Assembly drawings/dimension sheets
9.2 Dimension drawing 1FT2, shaft height 48
1FT2 synchronous motors for SINAMICS S120
128 Configuration Manual, 03/2021, A5E50645584B AA
9.2 Dimension drawing 1FT2, shaft height 48
All dimensions are in mm.
①
Option shaft with feather key
SIMOTICS S-1FT2
Shaft height 48
Motor length
Without brake
With brake
DIN
k
o
k1
o1
IEC
LB
-
LB1
-
1FT2205-2
145
28
188
34
1FT2205-4
177
220
