1FT2 synchronous motors for SINAMICS S120
Configuration Manual, 03/2021, A5E50645584B AA
57
5.1 Configuring software
5.1.1 SIZER configuration tool
Overview
The SIZER calculation tool supports you in the technical dimensioning of the hardware and
firmware components required for a drive task.
SIZER supports the following configuration steps:
• Configuring the power supply
• Designing the motor and gearbox, including calculation of mechanical transmission
elements
• Configuring the drive components
• Compiling the required accessories
• Selection of the line-side and motor-side power options
The configuration process produces the following results:
• A parts list of components required (Export to Excel)
• Technical specifications of the system
• Characteristic curves
• Comments on system reactions
• Installation information of the drive and control components
• Energy considerations of the configured drive systems
You can find additional information that you can download in the Internet at SIZER
(https://support.industry.siemens.com/cs/ww/en/ps/13434).
