Description of the motors
2.4 Selection based on the article number
1FT2 synchronous motors for SINAMICS S120
28 Configuration Manual, 03/2021, A5E50645584B AA
Description
Position of the article number
1 2 3 4 5 6 7 - 8 9 1
0
1
1
1
2
- 1
3
1
4
1
5
1
6
- Z
Shaft geometry
Plain shaft (without keyway)
0
Shaft with feather key
1
Plain shaft, alternative shaft exten-
sion
(11 mm x 23 mm),
for 1FT2☐03 only
0
3
0
2
Plain shaft, alternative shaft exten-
sion
(14 mm x 30 mm),
for 1FT2☐04 only
0
4
0
2
Encoder
Absolute encoder, singleturn, 22-bit (encoder AS22DQC)
S
Absolute encoder, multiturn, 22-bit + 12-bit (encoder AM22DQC)
M
Connection type
2CC (two-wire technology) for S120
B
Revision number
Start
0
Options
Version for increased chemical resistance
N16
Metal rating plate instead of adhesive label
Q31
Connection to equalize pressure
Q20
Paint finish
Jet black matt
RAL 9005
X01
Cream
RAL 9001
X02
Reseda green
RAL 6011
X03
Pebble gray
RAL 7032
X04
Sky blue
RAL 5015
X05
Light ivory
RAL 1015
X06
White aluminum
RAL 9006
X08
