Technical data and characteristics
6.2 Motor overview/Motor Module assignment/power cables
1FT2 synchronous motors for SINAMICS S120
Configuration Manual, 03/2021, A5E50645584B AA
75
SINAMICS S120 Booksize, DC link voltages 510 V DC to 720 V DC, line voltages 3 AC
380 V to 480 V
You can find the suitable SINAMICS Motor Modules in the following tables.
Motor data Combination with Motor Module SINAMICS S120 Booksize C/D
type
Article num-
ber
Moment of
inertia
JMot / kg cm
2
Static / max.
torque
M0 / Mmax / Nm
Static / max. torque in
combination with S120
Booksize C/D type
M
0 Inv / Mmax Inv / Nm
Article number for
S120 Booksize C/D
type
6SL3120-…
Rated /
max. current for
S120 Booksize C/D
type
IN / Imax Inv / A
1FT2 High Dynamic
1FT2104-4AF
0.35
1.27 / 3.75
1.27 / 3.75
...-☐TE13-0AD☐
3 / 9
1FT2104-5AF
0.56
2.4 / 7.5
2.4 / 7.5
...-☐TE13-0AD☐
3 / 9
1FT2104-6AF
0.76
3.2 / 10
3.2 / 10
...-☐TE21-0AD☐
9 / 27
1FT2105-4AF
1.7
5 / 15
5 / 15
...-☐TE21-0AD☐
9 / 27
1FT2105-4AH
1.7
5 / 15
5 / 15
...-☐TE21-0AD☐
9 / 27
1FT2105-6AF
2.7
8 / 24
8 / 24
...-☐TE21-0AD☐
9 / 27
1FT2106-3AF
4.6
9 / 24.5
8.8 / 18.38
...-☐TE21-0AD☐
9 / 27
1FT2106-4AF
6
12 / 32.5
12 / 29.25
...-☐TE21-8AC☐
18 / 36
1FT2106-6AF
8.7
16 / 42
16 / 42
...-☐TE21-8AD☐
18 / 54
1FT2 Compact
1FT2204-5AF
1.2
2.4 / 7.1
2.4 / 7.1
...-☐TE13-0AD☐
3 / 9
1FT2204-5AK
1.2
2.4 / 7.1
1.64 / 4.5
...-☐TE13-0AD☐
3 / 9
1FT2204-6AF
1.6
3.2 / 9.5
3.2 / 8.64
...-☐TE13-0AD☐
3 / 9
1FT2205-2AF
3.2
3.6 / 10.8
3.6 / 10.23
...-☐TE13-0AD☐
3 / 9
1FT2205-4AF
5.1
6 / 18
6 / 17.88
...-☐TE15-0AD☐
5 / 15
1FT2206-2AF
7.8
6.5 / 18
6.5 / 15.17
...-☐TE15-0AD☐
5 / 15
1FT2206-2AH
7.8
6.5 / 18
6.5 / 18
...-☐TE21-0AD☐
9 / 27
1FT2206-4AF
15
12 / 36
12 / 32.95
...-☐TE21-0AD☐
9 / 27
1FT2206-4AH
15
12 / 36
12 / 29.45
...-☐TE21-8AC☐
18 / 36
1FT2208-3AC
30
18 / 51
18 / 51
...-☐TE21-8AC☐
18 / 36
1FT2208-3AF
27
18 / 51
18 / 51
...-☐TE21-8AD☐
18 / 54
1FT2208-4AC
39
22 / 66
22 / 66
...-☐TE21-8AD☐
18 / 54
1FT2208-4AF
39
22 / 66
22 / 64.8
...-☐TE21-8AD☐
18 / 54
1FT2208-5AC
48
27 / 80
27 / 80
...-☐TE21-8AD☐
18 / 54
1FT2210-3AB
89
30 / 90
30 / 90
...-☐TE21-8AD☐
18 / 54
1FT2210-3AC
89
30 / 90
30 / 88.36
...-☐TE21-8AD☐
18 / 54
1FT2210-3AF
89
30 / 90
30 / 87.57
...-1TE22-4AD☐
24 / 72
1FT2210-4AB
120
40 / 120
40 / 120
...-☐TE21-8AD☐
18 / 54
1FT2210-4AC
120
40 / 120
40 / 117.82
...-☐TE21-8AD☐
18 / 54
1FT2210-4AF
120
40 / 120
40 / 120
...-1TE23-0AD☐
30 / 90
1FT2210-5AC
150
50 / 150
50 / 150
...-1TE23-0AD☐
30 / 90
