Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
24 A5E36037886-003, 04/2017
Parameter
Description
Environ-
mental
condi-
tions
Surrounding air
temperature
Opera-
tion
0 °C to 45 °C: without power derating
45 °C to 55 °C: with power derating
Storage
-40 °C to +70 °C
Ambient humidi-
ty
Opera-
tion
< 90% (non-condensing)
Storage
90% (non-condensing)
Operating environment Indoors (without direct sunlight), free from corrosive gas, combustible gas, oil
gas, or dust
Altitude
≤ 1000 m (without power derating)
Degree of protection
IP 20
Degree of pollution
Class 2
Vibration Operation Shock Operational area II
Peak acceleration: 5 g, 30 ms and 15 g, 11 ms
Quantity of shocks: 3 per direction × 6 directions
Duration of shock: 1 s
Vibration Operational area II
10 Hz to 58 Hz: 0.075 mm deflection
58 Hz to 200 Hz: 1 g vibration
Product packag-
ing
Vibration 2 Hz to 9 Hz: 3.5 mm deflection
9 Hz to 200 Hz: 1 g vibration
Quantity of cycles: 10 per axis
Sweep seed: 1 octave/min
Certifica-
tion
UL, CE, KC, RCM, EAC
1)
When SINAMICS V90 works with a motor with a brake, the voltage tolerance of 24 VDC power supply must be -10% to
+10% to meet the voltage requirement of the brake.
2)
Integral solid state short circuit protection does not provide branch circuit protection. Branch circuit protection must be
provided in accordance with the National Electrical Code and any additional local codes.
3)
The V90 200 V servo drive has an overvoltage threshold of 410 VDC and an undervoltage threshold of 150 VDC; the
V90 400 V servo drive has an overvoltage threshold of 820 VDC and an undervoltage threshold of 320 VDC.
4)
SINAMICS V90 does not support motor overtemperature protection. Motor overtemperature is calculated by I
2
t and
protected by the output current from the drive.
