Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
26 A5E36037886-003, 04/2017
SINAMICS V90 400 V variant
Order No.
6SL3210-5FE...
10-
4UA0
10-
8UA0
11-
0UA0
11-
5UA0
12-
0UA0
13-
5UA0
15-
0UA0
17-
0UA0
Frame size
FSAA
FSA
FSA
FSB
FSB
FSC
FSC
FSC
Rated output current (A)
1.2
2.1
3.0
5.3
7.8
11.0
12.6
13.2
Max. output current (A)
3.6
6.3
9.0
13.8
23.4
33.0
37.8
39.6
Max. supported motor power (kW)
0.4
0.75
1.0
1.75
2.5
3.5
5.0
7.0
Power loss
1)
Main circuit (W)
12
29
32
84
96
92
115
138
Regenerative resistor
(W)
17 57 57 131 131 339 339 339
Control circuit (W)
32
32
35
35
35
36
36
36
Total (W)
61
118
124
250
262
467
490
513
Output frequency (Hz)
0 to 330
Power sup-
ply
Voltage/frequency
3-phase 380 VAC to 480 VAC, 50/60 Hz
Permissible voltage fluc-
tuation
-15% to +10%
Permissible frequency
fluctuation
-10% to +10%
Permissible supply con-
figuration
TN, TT, IT
Rated input current (A)
1.5
2.6
3.8
6.6
9.8
13.8
15.8
16.5
Power supply capacity
(kVA)
1.7 3.0 4.3 7.6 11.1 15.7 18.0 18.9
Inrush current (A)
8.0
8.0
8.0
4.0
4.0
2.5
2.5
2.5
Cooling method
Self-cooled
Fan-cooled
Mechanical
design
Outline dimensions (W x
H x D, mm)
60 x
180 x
200
80 x 180 x 200 100 x 180 x 220 140 x 260 x 240
Weight (kg)
1.800
2.500
2.510
3.055
3.130
6.515
6.615
6.615
1)
The values here are calculated at rated load.
