Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
A5E36037886-003, 04/2017
29
Article No.
1FL60...
42
44
61
62
64
66
67
90
92
94
96
Operating temperature [°C]
0 to 40 (without power derating)
Storage temperature [°C]
-20 to +65
Maximum noise level [dB]
65
70
70
Holding
brake
Rated voltage
(V)
24 ± 10%
Rated current
(A)
0.88 1.44 1.88
Holding brake
torque [Nm]
3.5 12 30
Maximum
brake opening
time [ms]
60 180 220
Maximum
brake closing
time [ms]
45 60 115
Maximum
number of
emergency
stops
2000
3)
Oil seal lifetime [h]
5000
Encoder lifetime [h]
> 20000
4)
Degree of protection
IP65, with shaft oil seal
Weight of
incremen-
tal encoder
motor [kg]
With brake
2)
4.6/4.
8
6.4/6.
6
8.6/8.
8
11.3/1
0.1
11.3/1
1.5
14.0/1
4.2
16.6/1
6.8
21.3/2
1.5
25.7/2
5.9
30.3/3
0.5
39.1/3
9.3
Without brake
2)
3.3/3.
4
5.1/5.
2
5.6/5.
7
8.3/7.
0
8.3/8.
4
11.0/1
1.1
13.6/1
3.7
15.3/1
5.4
19.7/1
9.8
24.3/2
4.4
33.2/3
3.3
Weight of
absolute
encoder
motor [kg]
With brake
2)
4.4/4.
5
6.2/6.
3
8.3/8.
4
11.0/9
.7
11.0/1
1.1
13.6/1
3.7
16.3/1
6.4
20.9/2
1.0
25.3/2
5.4
29.9/3
0.0
38.7/3
8.8
Without brake
2)
3.1/3.
2
4.9/5.
0
5.3/5.
4
8.0/6.
7
8.0/8.
1
10.7/1
0.8
13.3/1
3.4
14.8/1
4.9
19.3/1
9.4
23.9/2
4.0
32.7/3
2.8
1)
When the surrounding temperature is higher than 30 °C, the 1FL6096 motors with brake will have a power derating of
10%.
2)
The former value indicates the data for high inertia motors with straight connectors; the latter value indicates the data for
high inertia motors with angular connectors.
3)
Restricted emergency stop operation is permissible. Up to 2000 braking operations can be executed with 300% rotor
moment of inertia as external moment of inertia from a speed of 3000 rpm without the brake being subject to an inad-
missible amount of wear.
4)
This lifetime is only for reference. When a motor keeps running at 80% rated value and the surrounding temperature is
30 °C, the encoder lifetime can be ensured.
Note
The data of rated torque, rated power, and maximum torque in
the above table allows a tolerance of 10%.
