Siemens SIMOTICS XP User Manual

Spare parts
10.10 Machine parts
1MB..1/2/3/4 - shaft heights 63 ... 355
136 Operating Instructions, 06/2020, A5E44455710A
Part
Description
Part
Description
5.00
Terminal box, complete
6.23
Shaft sealing ring
5.03
Seal (upper terminal box section)
6.25
Lubrication sleeve
5.04
Seal (adapter plate)
6.26
Cover
5.06
Mounting rail
6.29
Screw
5.10
Complete terminal board
6.31
Nut
5.11
Terminal block
6.65
Grease nipple
5.13
Link rail
6.74
Sleeve
5.17
Screw
6.75
Screw
5.18
Spring lock washer
7.00
Ventilation system, complete
5.19
Screw
7.04
Fan
5.21
Screw (drilled)
7.12
Locking ring
5.27
Terminal clamp
7.40
Fan cover
5.29
Lower saddle terminal
7.48
Washer
5.35
Cable entry
7.49
Screw
5.36
Spring lock washer
Tools for mounting and withdrawing rolling bearings; fans and drive output elements cannot be supplied.
