Siemens SIMOTICS XP - Explosion Hazard Due to Overheating of the Rolling Bearings

Spare Parts
10.9 Machine parts
1MB..5/6 shaft height 71 ... 355
126 Operating Instructions, 07/2020, A5E41926185A
Part
Description
Part
Description
5.20
Cable entry
7.49
Screw
5.22
Stud-type bushing
8.00
Auxiliary terminal box
5.25
Spring washer
8.01
Screw
5.26
Nut
8.02
Auxiliary terminal box cover
5.27
Terminal clamp
8.03
Seal
5.29
Lower saddle terminal
8.04
Side wall/flange
5.35
Special nut
8.05
Terminal block
5.36
Spring washer
8.06
Screw
5.37
Spring washer
8.07
End bracket
5.43
Entry plate
8.08
Screw
5.44
Terminal box top side
8.09
Standard mounting rail
5.47
Screw
8.10
Screw
5.48
Spring washer
8.11
Spring washer
5.49
Screw
8.12
Auxiliary terminal box housing
5.52
Cable entry
8.13
Sealing plug
5.53
Sealing plug
8.14
O ring
5.55
Nut
8.15
Seal
5.63
Mounting rail
8.16
Screw
Tools for mounting and withdrawing rolling bearings; fans and output transmission elements cannot be supplied.
