Description
3.3 Design
1MB..5/6 shaft height 71 ... 355
Operating Instructions, 07/2020, A5E41926185A
29
3.3.9 Optional built-on and built-in accessories
Machines can be equipped with the following integrated components/devices:
• Temperature sensors integrated in the stator winding in order to monitor the temperature
and protect the stator winding from overheating.
• Anti-condensation heating for machines whose windings are subject to a risk of
condensation due to the climatic conditions.
Machines can be equipped with the following mounted components/devices:
• Brake
• Rotary pulse encoder
• External fan (forced ventilation)
• Measuring nipple for SPM shock pulse measurement for bearing monitoring
• Backstop
Observe all of the other documents provided with this machine.
Supplementary devices
Depending on the order, various supplementary devices can be installed or mounted. These
include sensors for bearing temperature monitoring or winding monitoring, for example.
Risk of explosion during operation due to too high surface temperature
This can result in death, serious injury, or material damage.
• Prevent the maximum surface temperature from being exceeded by maintaining the
specified operating conditions.
• Monitor the coil temperature. Use the temperature sensor that is built into the stator
winding for this as specified on the rating plate or extra rating plate.
