Terminal Module TM15
6SL3055-0AA00-3FAx
Unit Value
● Output voltage drop
(I/O power supply to the output)
V
DC
0.5
● Max. total current of the outputs (per group)
to 60 °C
to 50 °C
to 40 °C
A
DC
A
DC
A
DC
2
3
4
IEC enclosure specification IP20 degree of protection
Protective-conductor connection On the housing with M4/1.8 Nm screw
Response time The response time for the digital inputs/outputs (TM15 DI/DO) consists
of the following elements:
● Response time on the component itself (approx. 1/2 DRIVE-CLiQ
cycle).
● Transmission time via the DRIVE-CLiQ connection (approx. 1
DRIVE-CLiQ cycle).
● Evaluation on the control unit (see function diagram)
References: SINAMICS S List Manual, chapter "Function diagrams".
Weight kg 0.86
Approval UL and cULus
http://www.ul.com
File: E164110, Vol. 2, Sec. 9
1) Pure hardware delay
Terminal Module TM15
2.8 Technical data
TM15 / TM17 High Feature Terminal Modules
34 Manual, 11/2016
