3.3.8 Description of the LEDs on Terminal Module TM17 High Feature
Table 3-8 Description of the LED
LED Color State Description
READY
- OFF Electronics power supply outside permissible tolerance range.
Green Continuous The component is ready for operation and cyclic DRIVE-CLiQ com‐
munication is taking place.
Orange Continuous DRIVE-CLiQ communication is being established.
Red Continuous At least one fault is present in this component.
Green/red Flashing
2 Hz
Firmware is being downloaded.
Green/Or‐
ange
Flashing
2 Hz
Component detected: no fault present
Red/Orange Flashing
2 Hz
Component detected: Fault(s) present
Cause and rectification of faults
The following reference contains information about the cause of faults and how they can be
rectified:
● SIMOTION D4x5 Commissioning and Hardware Installation Manual
● TM15 / TM17 High Feature Commissioning Manual
Terminal Module TM17 High Feature
