2.8 Technical data
Table 2-9 Technical data
Terminal Module TM15
6SL3055-0AA00-3FAx
Unit Value
Electronic power supply
Voltage
Current (without DRIVE-CLiQ or digital outputs)
Power loss
V
DC
A
DC
W
24 DC (20.4 – 28.8)
0.15
<3
Ambient temperature up to an altitude of 2000 m °C 0 - 60
Storage temperature °C -40 to +85
Relative humidity 5% to 95%, no condensation
I/O
● Digital inputs/outputs
Each can be parameterized separately as DI or DO
● Number of digital inputs/outputs
24
● Isolation
Yes, in groups of 8
● Max. cable length
m 30
Digital inputs
● Voltage
V
DC
-30 to +30
● Low-level (an open digital input is interpreted as
"low")
V
DC
-30 to +5
● High level
V
DC
15 to 30
● Input impedance
kΩ 2.8
● Current consumption (at 24 V DC), typical
mA 9
● Max. voltage in OFF state
V
DC
5
● Current in OFF state
mA 0.0 to 1.0 (per channel)
● Input delay of digital inputs, typical
1)
μs For "0" to "1" 50
For "1" to "0" 100
Digital outputs (sustained short-circuit-proof)
● Voltage
V
DC
24
● Max. load current per digital output
A
DC
0.5
● Output delay (ohmic load)
● typical
μs For "0" to "1" 50
For "1" to "0" 150
● maximum
μs For "0" to "1" 100
For "1" to "0" 225
● Min. output pulse
(100% amplitude, 0.5 A with resistive load)
μs 125 (typ.)
350 (max.)
● Max. switching frequency
(100% amplitude, 50%/50% duty cycle, with 0.5
A and a resistive load)
kHz 1 (typ.)
● Voltage drop in ON state
V
DC
0.75 (max.) with all circuits fully loaded
● Leakage current in OFF state
μA max. 10 per channel
Terminal Module TM15
2.8 Technical data
TM15 / TM17 High Feature Terminal Modules
Manual, 11/2016 33
