Note
The two "+" and "M" terminals are jumpered in the connector and not in the device. This ensures
that the supply voltage is looped through.
The current consumption increases by the value for the DRIVE-CLiQ node. The digital outputs
are supplied via terminals X520, X521, and X522.
Requirements for the power supply
Requirements for the power supply are as follows:
Table 3-4 Requirements for the electronic power supply
Parameter Requirement
Current 200 mA
1
per module (TM17 High Feature)
1
Does not include the current provided for the DI/O or for the DRIVE-CLiQ Interface.
The maximum supply current for TM17 High Feature is calculated from the sum of the 3
currents below:
● 200 mA, maximum, via X524 connection
(module logic must always be taken into account)
● 450 mA, maximum, via X524
(24 V supply via DRIVE-CLiQ; relevant only if a module connected downcircuit of the TM17
High Feature is supplied via DRIVE-CLiQ, e.g. encoder without a separate 24 V connection)
● 16 x 0.5 A, maximum, via X520/X521/X522
(all channels are parameterized as DO and charged with 0.5 A)
The terminal module monitors the electronic power supply for both overvoltage and
undervoltage conditions.
Note
Avoid long cables. The 24 VDC power supply should be located as close as possible to the
terminal modules. The total length of all power cables, when added together, must not exceed
10 meters.
Terminal Module TM17 High Feature
3.3 Description of Ports
TM15 / TM17 High Feature Terminal Modules
Manual, 11/2016 41
