Connecting cable
Details about the bus cable, bus connector and installation can be found in chapter
Networking (Page 119).
Note
The maximum cable length is 100 m.
The terminating resistor must be switched in (switch position "On") at the beginning and end
of the bus segment. See figure "Bus connector (6ES7 ...): Terminating resistor connected and
disconnected" in chapter Network components for a PROFIBUS subnet (Page 122)
Connecting
6.1 Wiring
SIMOTION C
108 Operating Instructions, 11/2016, A5E33441428B
