Page #117 background imageLoading...
Page #117 background image
Design of the shield connecting element
The shield connecting element consists of:
Retaining bracket with two screw bolts to mount the shield connecting element on the
mounting rail (Article No.: 6ES5 390-5AA00-0AA0)
The shielding terminals
You must use the following shielding terminal, depending on the cable cross-section used:
Table 6-7 Assignment of cable cross-sections and shielding terminals
Wire with shield diameter Shielding terminal
Article No. :
2 cables, each with 2 to 6 mm shield diameter 6ES7 390-5AB00-0AA0
1 cable with 3 to 8 mm shield diameter 6ES7 390-5BA00-0AA0
1 cable with 4 to 13 mm shield diameter 6ES7 390-5CA00-0AA0
The shield connecting element is 80 mm wide and provides space for two rows, each with four
shielding terminals.
Connecting
6.1 Wiring
SIMOTION C
Operating Instructions, 11/2016, A5E33441428B 117
