System clocks C230-2 C240 C240 PN
Interpolator cycle clock (IPO cycle clock) ≥ 1.5 ms ≥ 0.5 ms
Send cycle of PROFINET (C240 PN) - - 0.5 to 4 ms
A modification can be made in the engineering system.
For system cycle clock settings, refer to the SIMOTION SCOUT online help.
Note
With the SIMOTION C, errors can occur during Download or during the transition from STOP
to RUN if I/O bus modules and a system cycle clock > 8 ms (only with equidistant bus cycle)
are used. If an error occurs, set the system cycle clock ≤ 8 ms.
DP slave connections
Table 11-4 Number of DP slave connections
Number of DP slave connections Max. 64
PROFINET device connections
Table 11-5 Number of PROFINET device connections
Number of PROFINET device connections Max. 64
Address areas
Table 11-6 Address areas
Input address area, total
● 2 Kbytes for C230-2
● 4 Kbytes for C240 / C240 PN
Output address area, total
● 2 Kbytes for C230-2
● 4 Kbytes for C240 / C240 PN
Process image inputs 64 bytes
Process image outputs 64 bytes
Connection values
Table 11-7 Connection values
Supply voltage 24 V DC (permissible range: 20.4 to 28.8 V)
Power consumption from 24 V
● typically 0.9 A (inputs/outputs open)
● typically 1.2 A (with 4 encoders, 5 V)
● typically 1.9 A (with 4 encoders, 24 V)
Power loss 15 W
Technical data
11.1 Technical data
SIMOTION C
164 Operating Instructions, 11/2016, A5E33441428B
