Starting current 8 A
Encoder supply 5 V max. output current 1.2 A
Encoder supply 24 V max. output current 1.2 A
Dimensions and weight
Table 11-8 Dimensions and weight
Dimensions W x H x D [mm] 200 x 125 x 118
Weight [g] Approximately 1 150
Onboard drive interface (C230-2, C240)
Analog
Table 11-9 Onboard drive interface
Setpoint signal (analog output)
Number 4
Rated voltage range -10.5 to 10.5 V
Output current -3 to 3 mA
Electrically isolated No
Load impedance ≥ 3 kOhm
Resolution
● 16-bit, including sign (with filter)
● 12-bit, including sign (without filter)
Filter time
● C230-2
● C240
● With filter (C230-2-compatible)
● With filter (C230-2 compatible) or without filter (can
be switched in HW Config)
Basic error limit (at 25° C)
● 0 V to 10 V
● -10 V to 0 V
● -2 to +6 % (typically +3 %)
● -6 to +2 % (typically -3 %)
Relay contact controller enable
Number 4
Switching voltage max. 50 V
Switching current Max. 1 A
Switching capacity Max. 30 VA
Mechanical service life
Electrical service life
Usually 10
9
switching cycles
Typically 3 · 10
6
switching cycles at 24 V / 1 A
Cable length: Max. 35 m
Technical data
11.1 Technical data
SIMOTION C
Operating Instructions, 11/2016, A5E33441428B 165
