Figure 2-3 System overview of C240 PN
Components
The most important components of a SIMOTION application with SIMOTION C and their
functions are listed below.
Note
The modules and devices approved for the SIMOTION C are listed in the SIMOTION PM 21
Catalog . This document is supplied in electronic format with SIMOTION SCOUT.
Description
2.1 System overview
SIMOTION C
18 Operating Instructions, 11/2016, A5E33441428B
