Siemens simovert master drive User Manual

Spare Parts 08.96
7-10 Siemens AG 6SE7087-6BM70
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order No. No. Used in
+A10 -U1 (-A19, -A29, -A39),
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7036-5GK84-1JC0 6 6SE7041-4WM20
+A10 -U1 (-C110, -C120),
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AB64 4 6SE7041-0WM20
6SE7041-1WM20
+A10 -U1 (-C110, -C120),
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AC35 4 6SE7041-2WM20
+A10 -U1 (-C110, -C120),
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AC38 4 6SE7041-4WM20
6SE7041-6WM20
6SE7038-6WK20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Radial fan 6SY7000-0AB68 4 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Nozzle for the radial fan 6SY7000-0AB65 4 6SE7041-0WM20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Nozzle for the radial fan 6SY7000-0AB65 4 6SE7041-1WM20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Nozzle for the radial fan 6SY7000-0AB65 4 6SE7041-2WM20
+A10 -U1 (-F101, -F102),
+A12 -U1 (-F101, -F102)
Fused load
disconnector
6SY7000-0AA26 4 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 (-F101, -F102),
+A12 -U1 (-F101, -F102)
Fuse insert 6SY7000-0AC34 4 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
+A10 -U1 (-F101, -F102),
+A12 -U1 (-F101, -F102)
Fuse insert 6SY7000-0AC42 4 6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB77 8 6SE7041-0WM20
6SE7041-1WM20
+A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB87 8 6SE7041-2WM20
+A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB74 8 6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 (-R100, -R200, -R300),
+A12 -U1 (-R100, -R200, -R300)
Balancing resistor 6SY7000-0AA77 6 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
+A10 -U1 (-R100, -R200, -R300),
+A12 -U1 (-R100, -R200, -R300)
Balancing resistor 6SY7000-0AA76 6 6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 -R108, -R109, -R118, -R119, -R208, -R209, -
R218, -R219, -R308, -R309, -R318, -R319)
+A12 -U1 (-R108, -R109, -R118, -R119, -R208, -R209, -
R218, -R219, -R308, -R309, -R318, -R319)
Snubber resistor 6SY7000-0AB18 24 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 -A28,
+A12 -U1 -A28
VDU resistor 6SE7038-6GL84-1JB0 2 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 -G25,
+A12 -U1 -G25
PSU2 power supply
board
6SE7038-6GL84-1JA0 2 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
