08.96 Spare Parts
Siemens AG 6SE7087-6BM70
7-11
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order No. No. Used in
-G25 PSU2 power supply
board
6SE7038-6GL84-1JA0 1 6SE7033-0WJ20
6SE7033-5WJ20
6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
+A10 -U1 -R28,
+A12 -U1 -R28
VDU resistor 6SY7000-0AC33 2 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
-A10 CU2 open- and closed-
loop control board(VC)
6SE7090-0XX84-0AF0 1 6SE7033-0WJ20
6SE7033-5WJ20
6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AB12 12 6SE7034-5WK20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AB71 12 6SE7035-7WK20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AC36 12 6SE7036-5WK20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AC37 12 6SE7038-6WK20
-A100, -A110, -A200, -A210, -A300, -A310 IGBT transistor module 6SY7000-0AC36 6 6SE7033-0WJ20
-A100, -A110, -A200, -A210, -A300, -A310 IGBT transistor module
fz1200r16kf1, 1200a,
1600v
6SY7000-0AB14 6 6SE7033-5WJ20
-A108, -A109, -A208, -A209, -A308, -A309 SMU3 inverter snubber
board
6SE7038-6GK84-1GF0 6 6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
-A109, -A209, -A309 SMU3 inverter snubber
board
6SE7038-6GK84-1GF0 3 6SE7033-0WJ20
6SE7033-5WJ20
-A118, -A119, -A218, -A219, -A318, -A319 SML3 inverter snubber
board
6SE7038-6GK84-
1GG0
6 6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
-A119, -A219, -A319 SML3 inverter snubber
board
6SE7038-6GK84-
1GG0
3 6SE7033-0WJ20
6SE7033-5WJ20
-A19, -A29, -A39 IGD8 inverter gating
board
6SE7034-5GK84-1JC0 3 6SE7034-5WK20
-A19, -A29, -A39 IGD8 inverter gating
board
6SE7035-7GK84-1JC0 3 6SE7035-7WK20
-A19, -A29, -A39 IGD8 inverter gating
board
6SE7038-6GK84-1JC0 3 6SE7036-5WK20
-A19, -A29, -A39 IGD8 inverter gating
board
6SE7036-5GK84-1JC0 3 6SE7038-6WK20
-A20 IVI inverter interface
board
6SE7038-6GL84-1BG0 1 6SE7033-0WJ20
6SE7033-5WJ20
6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
