Siemens Simovert P 6SE21 Series User Manual

SIMOVERT P 6SE21 Series Inverters
English
Operating Instructions

Siemens plc 1995
G85139–A1615–U156–A
02.95
19
Typical Configuration Comments
2
3
1
3
7 – 33 V
Simple control.
Does not restart after mains
break.
Simple control.
Restarts after mains break.
OR
2
3
1
3
7 – 33 V
OR
2
3
4
Run/Stop
Control
Ramps
down at
a rate set
by P03
Edge–triggered,
Terminal X11.3.
Trip Inactive.
Level–triggered,
Terminal X11.3.
Trip Inactive.
Run–Down
Mode
Free runs
to a
standstill
000
(Factory
Setting)
002
001 003
PTC
2
3
4
OR
Simple Run/Stop control as
above, but high impedance >
2 k Ω X11.2 to X11.4 trips drive &
indicates F11.
Edge–triggered,
Terminal X11.3.
Trip active.
004 005
2
3
4
PTC
2
3
4
OR
Simple Run/Stop control.
Restarts after mains break.
High impedance > 2 k
Ω X11.2 to
X11.4 trips drive & indicates F11.
Level–triggered,
Terminal X11.3.
Trip active.
006 007
2
3
4
2
3
4
OR
RUN RUN
STOP
STOP
Inverter starts when RUN button
is pressed (momentary action).
inverter stops when STOP button
pressed (momentary action,
normally closed). PTC may also
be used, but no fault will be
indicated.
Push–button
controls
008 009
P05 Setting
Do not restart the inverter or reconnect it to a motor which is already running. Wait for the motor to
stop and the inverter to reach zero output frequency before attempting to run the motor/inverter
combination again.
If required, a running restart facility is provided by parameter P42
(see section 5.3.2) .
CAUTION
The three run–down modes operate as follows:
Ramp–Down
(P05 = 000, 004, 006 or 008)
The inverter output frequency will ramp–down at a rate set by parameter P03 until the minimum output
frequency (set by P07) is reached. At this point the inverter stops with no output.
Free Run
(P05 = 002, 003, 005, 007 or 009)
The inverter output stops immediately, allowing the motor to ‘freewheel’ to a standstill or to be stopped by other
means.
DC Injection Brake
DC injection braking is selected by setting parameter P11 to a value greater than zero. The inverter injects dc
into the motor for a period equivalent to the ramp–down time set by P03 plus one second.
