2. TECHNICAL DATA
Rated supply voltage: Models 6SE21**–1AA11
Models 6SE21**–3AA21
** – May be any number
1 AC 50/60 Hz +/–1%, 220 – 240 V +/–10%
3 AC 50/60 Hz +/–1%, 380 – 500 V +/–10%
Output voltage 0 V – rated supply voltage
Output frequency 0.0 – 400 Hz
Efficiency ≥ 0.94
Motor power factor ≤ 0.9 lagging/inductive
Ambient operating temperature
(unit must not be exposed to direct sunlight)
0 – 40
o
C
Storage/transport temperature –30 – +85
o
C
Degree of protection IP21 (NEMA 1)
Humidity 0 – 95% at 25
o
C
Frequency stability at T
max
10
o
C referred to f
max
Analogue setpoint 1%
Digital setpoint 0.01%
Frequency resolution 0.1 Hz
Overload rating 1.5 x rated current for up to 60 seconds
2.1 Equipment Ratings Table
Model
6SE21..
Input
Voltage
Range
Max.
Cont.
Input
Current
Circuit
Breaker
Constant Torque
Output
Variable Torque
Output **
Variable Torque
Output **
460 V (USA)
Variable Torque
Output **
500 V
Overload
Current
Model
6SE21..
Voltage
Range
Input
Current
Breaker
Continuous
Current
Motor
Rating *
Continuous
Current
Motor
Rating *
Continuous
Current
Motor
Rating *
Continuous
Current
Motor
Rating *
Current
01–1AA11
198–264 V
1 phase
9.8 A 16.0 A 2.8 A .55 kW 3.9 A .75 kW – – – – 4.2 A
02–1AA11
198–264 V
1 phase
13.5 A 16.0 A 3.9 A .75 kW 4.8 A 1.1 kW – – – – 5.8 A
03–1AA11
1 phase
26.5 A 32.0 A 6.8 A 1.5 kW 10.0 A 2.2 kW – – – – 10.2 A
03–3AA21 5.5 A 10.0 A 4.0 A 1.5 kW 5.5 A 2.2 kW 4.8 A 3 hp 4.8 A 2.2 kW 6.0 A
05–3AA21 10.0 A 16.0 A 7.6 A 3.0 kW 9.5 A 4.0 kW 8.1 A 5 hp 8.1 A 4.0 kW 11.4 A
08–3AA21 17.0 A 20.0 A 12.0 A 5.5 kW 17.0 A 7.5 kW 14.0 A 10 hp 12.0 A 7.5 kW 18.0 A
13–3AA21
342–550 V
3 phase
28.0 A 32.0 A 19.0 A 7.5 kW 23.0 A 11.0 kW 21.0 A 15 hp 19.0 A 11.0 kW 28.5 A
17–3AA21
342–550 V
3 phase
38.0 A 40.0 A 25.0 A 11.0 kW 32.0 A 15.0 kW 27.0 A 20 hp 25.0 A 15.0 kW 37.5 A
22–3AA21
40.0 A 50.0 A 32.0 A 15.0 kW 38.0 A 18.5 kW 34.0 A 25 hp 32.0 A 18.5 kW 48.0 A
27–3AA21 48.0 A 63.0 A 38.0 A 18.5 kW 46.0 A 22.0 kW 40.0 A 30 hp 38.0 A 22.0 kW 57.0 A
33–3AA21
70.0 A 80.0 A 46.0 A 22.0 kW 60.0 A 30.0 kW 52.0 A 40 hp 46.0 A 30.0 kW 69.0 A
42–3AA21 87.0 A 100.0 A 60.0 A 30.0 kW 75.0 A 37.0 kW 65.0 A 50 hp 60.0 A 37.0 kW 90.0 A
* Siemens 4–pole motor, 1LA5 series or equivalent.
** Automatically selected on voltage/frequency curve types 4 and 5 (see section 1.4.1).
2.2 Cable Lengths
The inverters will operate satisfactorily with unscreened cables of up to 150 m in length and screened or armoured
cable of up to 50 m in length. For applications where longer cables are required, inductors must be fitted to reduce
capacitive currents.
Note
If long cables are used, it may be necessary to change the value of parameter P52 to compensate for any
inaccuracies in the output current reading.
The following chokes are suitable for applications where up to 100/200 m screened/unscreened cables are required:
Model No.
Choke Type
6SE210*–1AA11 & 6SE2103–3AA21 4EP3601–8DB
6SE2105–/6SE2108–3AA21 4EP3801–4DB
6SE2113–/6SE2117–/6SE2122–3AA21 4EP3800–4DB
6SE2127–/6SE2133–3AA21 4EP4002–1DB
6SE2142–3AA21 4EU2421–8AA00
