8.7 Line reactor
Power Module PM240-2
132 Hardware Installation Manual, 01/2020, A5E33294624B AL
Table 8- 3 Technical data of the line reactors
Article number
Inductance
[mH]
Line/load connection
PE connection
Weight
[kg]
[mm
2
/ nM]
[AWG / lbf in]
[mm
2
/ lbf in]
6SL3203-0CE13-2AA0
2.5
2.5 / 0.8
14 / 7
M4 [3 / 26.5]
1.1
6SL3203-0CE21-0AA0
1
6 / 1.8
10 / 15.9
M4 [3 / 26.5]
2.1
6SL3203-0CE21-8AA0
0.5
6 / 1.8
10 / 15.9
M5 [5 / 44.3]
2.95
6SL3203-0CE23-8AA0
0.3
16 / 4
6 / 34.5
M5 [5 / 44.3]
7.80
The line reactors are designed to IP20 degree of protection.
Table 8- 4 Assignment table
Line reactors
Power Module, 400 V
Power Module, 200 V
6SL3203-0CE13-2AA0 6SL3210-1PE11-8 .L1
6SL3210-1PE12-3 .L1
6SL3210-1PE13-2 .L1
FSA / /
6SL3203-0CE21-0AA0 6SL3210-1PE14-3 .L1
6SL321 .-1PE16-1 .L1
6SL321 .-1PE18-0 .L1
FSA 6SL3210-1PB13-0 .L0
6SL321 .-1PB13-8 .L0
FSA
6SL3203-0CE21-8AA0 6SL3210-1PE21-1 .L0
6SL3210-1PE21-4 .L0
6SL321 .-1PE21-8 .L0
FSB 6SL3210-1PB15-5 .L0
6SL3210-1PB17-4 .L0
6SL321 .-1PB21-0 .L0
FSB
6SL3203-0CE23-8AA0 6SL3210-1PE22-7 .L0
6SL321 .-1PE23-3 .L0
FSC 6SL3210-1PB21-4 .L0
6SL321 .-1PB21-8 .L0
6SL321 .-1PC22-2 .L0
6SL321 .-1PC22-8 .L0
FSC
Line reactors for 1 AC 200 V
For converters with 1 AC 200 V connection, rather than the line reactors listed above, you
can also deploy the following or similar products:
● FSA:
NKE 10 / 2.93 (Block company)
● FSB
NKE 25 / 1.17 (Block company)
● FSC
NKE 35 / 1.46 (Block company)
The technical properties and statements made by the manufacturer apply.
