Siemens SINAMICS G120 - Connection; Overview of the Interfaces

Connection
4
4.1 Overview of the interfaces
Interfaces on the base of the control cabinet
;'0
;'
;
;
;
;
-XDM1 Line
-XD0 Motor, motor motor holding brake, temperature sensor
-X0, -X1, -X2 Digital inputs
-X3 Analog input
Distributed inverter box
Manual, 06/2018, A5E43491109B AB 11
