4.4 Cable entry
Using cable entries
Feed the following cables through the floor of the distributed inverter box:
● 24 V supply cable
● PROFINET cable
● Encoder cable
The bushing in the floor of the control cabinet ensures conformance with degree of protection
IP54
(QFRGHUb9SRZHUVXSSO\
352),1(7
Figure 4-2 Cable entry
