General information about SINAMICS Safety Integrated
3.2 Drive monitoring with or without encoder
Safety Integrated
30 Function Manual, 07/2016, A5E03264275A
In operation without encoder, the actual speed values are calculated from the measured
electrical actual values. Therefore, speed monitoring is also possible during operation
without encoder.
Table 3- 1 Overview of Safety Integrated functions
Functions
Abbr.
With
encoder
Without
encoder
Brief description
Basic Functions
Safe Torque Off
STO
Yes
Yes
Safe Torque Off
Safe Stop 1 SS1 Yes Yes Safe stop according to stop category 1
Safe Brake Control
SBC
Yes
Yes
Safe Brake Control
Extended Func-
tions
Safe Torque Off
STO
Yes
Yes
1)
Safe Torque Off
Safe Stop 1
SS1
Yes
Yes
1)
Safe stop according to stop category 1
Safe Brake Control
SBC
Yes
Yes
1)
Safe Brake Control
Safe Operating Stop
SOS
Yes
No
Safe monitoring of the standstill position
Safe Stop 2
SS2
Yes
No
Safe stop according to stop category 2
Safely-Limited Speed
SLS
Yes
Yes
1)
Safe monitoring of the maximum speed
Safe Speed Monitor
SSM
Yes
Yes
1)
Safe monitoring of the minimum speed
Safe Direction
SDI
Yes
Yes
1)
Safe monitoring of the direction of motion
Safely-Limited Position
SLP
Yes
No
Safely-limited position
Safe referencing/homing
SR
Yes
No
Safe referencing/homing
Transferring safe position
values
SP Yes Yes
1)
Transferring safe position values
Safe Brake Test SBT Yes No Safe test of the required holding torque of a
brake
Safe Acceleration Monitor
SAM
Yes
Yes
1)
Safe monitoring of drive acceleration
Safe Brake Ramp
SBR
No
Yes
1)
Safe braking ramp
Safe gearbox stage switch-
over
– Yes No –
1)
The use of this safety function without encoder is permitted only for induction motors or synchronous motors of the
SIEMOSYN series.
The configuration of the Safety Integrated functions and the selection of monitoring with or
without encoder is realized in the Safety screens of the STARTER or SCOUT tools.
