Siemens SINAMICS Series Function Manual

Safety Integrated
Function Manual, 07/2016, A5E03264275A
31
Description of Safety Integrated functions
4
Safety Integrated Basic Functions and Safety Integrated Extended Functions are described
in detail in the "SINAMICS S120 Safety Integrated Function Manual".
The "SINAMICS S120 Safety Integrated Function Manual" is available on the Internet at the
following address (https://support.industry.siemens.com/cs/ww/en/ps/13231/man).
4.1
Preconditions for Safety Integrated Basic Functions
The following prerequisites apply for operation of the Safety Integrated Basic Functions:
● For G150, S120 Cabinet Modules and S150:
Option K82 (Terminal Module for activation of the safety functions "Safe Torque Off" and
"Safe Stop 1"), for activation signals of 230 V and/or cable lengths of more than 30 m
● An activated current controller in the drive
● For the safe brake control:
– For G150, S120 Cabinet Modules and S150:
Option K88 (Safe Brake Adapter 230 VAC)
– For the G130 and S120 Chassis units:
Option SBA (Safe Brake Adapter)

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
