Parameter list
7.1 Introduction to parameters
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
119
BICO example
3 (QDEOH%,&2 RI',
3 /LQN'2WR',
9LUWXDOOLQNEHWZHHQ',DQG'2
%LW
',
'2
',
',
', ', ', ',
U
U
3
BICO or the binary interconnection technology can help the user to connect internal function
and values to realize more customized features.
BICO functionality is a different, more flexible way of setting and combining input and output
functions. It can be used in most cases in conjunction with the simple, access level 2
settings.
The BICO system allows complex functions to be programmed. Boolean and mathematical
relationships can be set up between inputs (digital, analog, serial etc.) and outputs (inverter
current, frequency, analog output, digital outputs, etc.).
The default parameter that a BI or CI parameter is connected to is shown in the Factory
default column of the parameter list.
Access level (P0003)
Defines the level of user access to parameter sets.
Access level Description Remarks
0 User-defined parameter list Defines a limited set of parameters to which the end
user has access. See P0013 for details on use.
1 Standard Allows access into most frequently used parameters.
2 Extended Allows extended access to more parameters.
3 Expert For expert use only.
4 Service Only for use by authorized service personnel,
password protected.
