Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
126 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
[1] Factor for kWh to CO2 conversion
r0043[0...2] Energy saved [kWh] - - - - - Float 2
Displays calculated energy saved
Index: [0] Energy saving in kWh
[1] Energy saving in currency
[2] Energy saving in CO2
r0050 CO / BO: Active
command data set
- - - - - U16 2
Displays currently active command data set.
0 Command data set 0 (CDS)
1 Command data set 1 (CDS)
2 Command data set 2 (CDS)
Note: See P0810
r0051[0...1] CO: Active inverter data
set (DDS)
- - - - - U16 2
Displays currently selected and active inverter data set (DDS).
0 Inverter data set 0 (DDS0)
1 Inverter data set 1 (DDS1)
2 Inverter data set 2 (DDS2)
Index: [0] Selected inverter data set
[1] Active inverter data set
Note: See P0820
r0052.0...15 CO / BO: Active status
word 1
- - - - - U16 2
Displays first active status word of inverter (bit format) and can be used to diagnose inverter status.
Bit Signal name 1 signal 0 signal
00 Inverter ready Yes No
01 Inverter ready to run Yes No
02 Inverter running Yes No
03 Inverter fault active Yes No
04 OFF2 active No Yes
05 OFF3 active No Yes
06 ON inhibit active Yes No
07 Inverter warning active Yes No
08 Deviation setpoint / act. value No Yes
09 PZD control Yes No
10 |f_act| >= P1082 (f_max) Yes No
11 Warning: Motor current / torque limit No Yes
12 Brake open Yes No
13 Motor overload No Yes
14 Motor runs right Yes No
15 Inverter overload No Yes
Dependency: r0052 bit 03 "Inverter fault active": Output of bit 3 (Fault) will be inverted on digital output (Low = Fault,
High = No Fault).
Note: See r2197 and r2198.
