Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
135
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P0307[0...2] Rated motor power 0.01 -
2000.00
0.75 C(1) - DDS Float 1
Nominal motor power [kW / hp] from rating plate.
Dependency: If P0100 = 1, values will be in [hp].
Changeable only when P0010 = 1 (quick commissioning).
Note: Default value is depending on inverter type and its rating data.
P0308[0...2] Rated motor cosφ 0.000 -
1.000
0.000 C(1) - DDS Float 1
Nominal motor power factor (cosφ) from rating plate.
Dependency: Changeable only when P0010 = 1 (quick commissioning).
Visible only when P0100 = 0 or 2, (motor power entered in [kW]).
Setting 0 causes internal calculation of value. The value is displayed in r0332.
P0309[0...2] Rated motor efficiency
[%]
0.0 - 99.9 0.0 C(1) - DDS Float 1
Nominal motor efficiency from rating plate.
Dependency: Changeable only when P0010 = 1 (quick commissioning).
Visible only when P0100 = 1, (i.e. motor power entered in [hp]).
Setting 0 causes internal calculation of value. The value is displayed in r0332.
P0310[0...2] Rated motor frequency
[Hz]
12.00 -
599.00
50.00 C(1) - DDS Float 1
Nominal motor frequency from rating plate.
Dependency: Changeable only when P0010 = 1 (quick commissioning).
Pole pair number recalculated automatically if parameter is changed.
Note: Changes to P0310 can influence the maximum motor frequency. For further information see P1082.
P0311[0...2] Rated motor speed
[RPM]
0 - 40000 1395 C(1) - DDS U16 1
Nominal motor speed from rating plate.
Dependency: Changeable only when P0010 = 1 (quick commissioning).
Setting 0 causes internal calculation of value.
Slip compensation in V/f control requires rated motor speed for correct operation.
Pole pair number recalculated automatically if parameter is changed.
Note: Default value is depending on inverter type and its rating data.
r0313[0...2] Motor pole pairs - - - - DDS U16 3
Displays number of motor pole pairs that the inverter is currently using for internal calculations.
Dependency: Recalculated automatically when P0310 (rated motor frequency) or P0311 (rated motor speed) is
changed.
r0313 = 1: 2-pole motor
r0313 = 2: 4-pole motor
...
P0314[0...2] Motor pole pair number 0 - 99 0 C(1) - DDS U16 3
Specifies number of pole pairs of motor.
Dependency: Changeable only when P0010 = 1 (quick commissioning).
Setting 0 causes r0313 (calculated motor pole pairs) to be used during operation. Setting to > 0 overrides
r0313.
P0314 = 1: 2-pole motor
P0314 = 2: 4-pole motor
...
