7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
139
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P0360[0...2] Main inductance [mH] 0.0 -
10000.0
10.0 U, T - DDS Float 3
Sets main inductance of the motor equivalent circuit (phase value).
Dependency: See P0354
Caution: The data of equivalent circuit relates to the star equivalent circuit. Any data of the delta equivalent circuit
available therefore must be transformed to the star equivalent circuit before entering into the inverter.
r0370[0...2] Stator resistance [%] - - - PERCEN
T
DDS Float 4
Displays standardized stator resistance of motor equivalent circuit (phase value).
r0372[0...2] Cable resistance [%] - - - PERCEN
T
DDS Float 4
Displays standardized cable resistance of motor equivalent circuit (phase value). It is estimated to be 20 %
of the stator resistance.
r0373[0...2] Rated stator resistance
[%]
- - - PERCEN
T
DDS Float 4
Displays rated stator resistance of the motor equivalent circuit (phase value).
r0374[0...2] Rotor resistance [%] - - - PERCEN
T
DDS Float 4
Displays standardized rotor resistance of the motor equivalent circuit (phase value).
r0376[0...2] Rated rotor resistance
[%]
- - - PERCEN
T
DDS Float 4
Displays rated rotor resistance of the motor equivalent circuit (phase value).
r0377[0...2] Total leakage reactance
[%]
- - - PERCEN
T
DDS Float 4
Displays standardized total leakage reactance of the motor equivalent circuit (phase value).
r0382[0...2] Main reactance [%] - - - PERCEN
T
DDS Float 4
Displays standardized main reactance of the motor equivalent circuit (phase value).
r0384[0...2] Rotor time constant [ms] - - - - DDS Float 3
Displays calculated rotor time constant.
r0386[0...2] Total leakage time
constant [ms]
- - - - DDS Float 4
Displays total leakage time constant of motor.
r0395 CO: Total stator
resistance [%]
- - - PERCEN
T
- Float 3
Displays stator resistance of motor of combined stator / cable resistance.
P0503[0...2] Enable Keep-running
Operation
0 - 1 0 T - - U16 3
Enables keep-running operation. This attempts to prevent the inverter from tripping by enabling all possible
existing de-rating features, and the automatic restart function. May be used with P2113 = 1 to mask
resulting warnings from the user.
0 Keep-running mode disabled
1 Keep-running mode enabled
Index: [0] Inverter data set 0 (DDS0)
[1] Inverter data set 1 (DDS1)
[2] Inverter data set 2 (DDS2)
