Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
140 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Notice: P0503 = 1
Sets the following parameter values to minimize likelihood of a trip:
P0290 = 2
P1210 = 7
P1211 = 10
P1240 = 3
P0503 = 0
Resets the parameters to their default values:
P0290 = 2
P1210 = 1
P1211 = 3
P1240 = 1
Note: See also:
P0290
P1210
P1211
P1240
P2113
P0507 Application macro 0 - 255 0 C(1) - - U16 1
Selects a given Application macro, which is a set of parameter values for a given application. There are a
number of application macros covering a set of basic applications such as simple pump, conveyor,
compressor etc.
Note: Please note that to guarantee correct setting of the Application macro, the Application macro number
should only be changed during Setup directly after a parameter reset.
P0511[0...2] Scaling for display 0.00 -
100.00
[0] 1.00
[1] 1.00
[2] 0.00
U, T - - Float 3
Allows operator to enter the scaling factors for the display of motor frequency.
Index 0 = value of multiplier (a)
Index 1 = value of divisor (b)
Index 2 = value of constant (c)
With the parameter set to a non-default value the displayed value for frequency and setpoint on internal
and external BOPs is scaled accordingly. Note - the units "Hz" is no longer displayed if the value is scaled.
The formula used to scale the display is: (a / b)*N + c.
Index: [0] Multiplier for Scaling for display
[1] Divider for Scaling for display
[2] Constant for Scaling for display
r0512 CO: Scaled filtered
frequency
- - - - - Float 2
Displays actual inverter output frequency (r0024) excluding slip compensation (and resonance damping,
frequency limitation in V/f mode).
P0604[0...2] Threshold motor
temperature [°C]
0.0 - 200.0 130.0 U, T - DDS Float 2
Enters warning threshold for motor temperature protection. The trip temperature defined is always 10 %
higher than the warning threshold P0604. When actual motor temperature exceeds warning temperature
then inverter reacts as defined in P0610.
Dependency: This value should be at least 40°C higher than the motor ambient temperature P0625.
