Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
143
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
2 ON reverse / OFF1
3 OFF2 - coast to standstill
4 OFF3 - quick ramp-down
9 Fault acknowledge
10 JOG right
11 JOG left
12 Reverse
13 MOP up (increase frequency)
14 MOP down (decrease frequency)
15 Fixed frequency selector bit0
16 Fixed frequency selector bit1
17 Fixed frequency selector bit2
18 Fixed frequency selector bit3
22 QuickStop Source 1
23 QuickStop Source 2
24 QuickStop Override
25 DC brake enable
27 Enable PID
29 External trip
33 Disable additional freq setpoint
99 Enable BICO parameterization
Dependency: Setting 99 (enable BICO parameterization) requires:
• P0700 command source or
• P0010 = 1, P3900 = 1, 2 or 3 (quick commissioning) or
• P0010 = 30, P0970 = 1 factory reset in order to reset
Note: "ON / OFF1" can only be selected for one digital input (e.g. P0700 = 2 and P0701 = 1). Configuring DI2
with P0702 = 1 will disable DI1 by setting P0701 = 0. Only the last activated digital input serves as a
command source. "ON / OFF1" on a digital input can be combined with "ON reverse / OFF1" on another
digital input.
P0702[0...2] Function of digital input 2 0 - 99 0 T - CDS U16 2
Selects function of digital input 2.
See P0701.
P0703[0...2] Function of digital input 3 0 - 99 9 T - CDS U16 2
Selects function of digital input 3.
See P0701.
P0704[0...2] Function of digital input 4 0 - 99 15 T - CDS U16 2
Selects function of digital input 4.
See P0701.
P0712 [0...2] Analog / digital input 1 0 - 99 0 T - CDS U16 2
Selects function of digital input AI1 (via analog input).
See P0701.
Note: See P0701. Signals above 4 V are active; signals below 1.6 V are inactive.
P0713[0...2] Analog / digital input 2 0 - 99 0 T - CDS U16 2
Selects function of digital input AI2 (via analog input).
See P0701.
