Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
144 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Note: See P0701. Signals above 4 V are active; signals below 1.6 V are inactive.
P0717 Connection macro 0 - 255 0 C(1) - - U16 1
Selects a given connection macro, which is a set of parameter values for a given set of control
connections. There are a number of connection macros which define basic control connection settings
such as Terminals, BOP, PID with analog setpoint etc.
Note: Please note that to guarantee correct setting of the Connection macro, the Connection macro number
should only be changed during Setup directly after a parameter reset.
P0719[0...2] Selection of command &
frequency setpoint
0 - 57 0 T - CDS U16 4
Central switch to select control command source for inverter. Switches command and setpoint source
between freely programmable BICO parameters and fixed command / setpoint profiles. Command and
setpoint sources can be changed independently. The tens digit chooses the command source and the
units digit chooses the setpoint source.
0 Cmd = BICO parameter, Setpoint = BICO parameter
1 Cmd = BICO parameter, Setpoint = MOP setpoint
2 Cmd = BICO parameter, Setpoint = Analog setpoint
3 Cmd = BICO parameter, Setpoint = Fixed frequency
4 Cmd = BICO parameter, Setpoint = USS on RS232 (reserved)
5 Cmd = BICO parameter, Setpoint = USS on RS485
7 Cmd = BICO parameter, Setpoint = Analog setpoint 2
40 Cmd = USS on RS232 (reserved), Setpoint = BICO parameter
41 Cmd = USS on RS232 (reserved), Setpoint = MOP setpoint
42 Cmd = USS on RS232 (reserved), Setpoint = Analog setpoint
43 Cmd = USS on RS232 (reserved), Setpoint = Fixed frequency
44 Cmd = USS on RS232 (reserved), Setpoint = USS on RS232 (reserved)
45 Cmd = USS on RS232 (reserved), Setpoint = USS on RS485
47 Cmd = USS on RS232 (reserved), Setpoint = Analog setpoint 2
50 Cmd = USS on RS485, Setpoint = BICO parameter
51 Cmd = USS on RS485, Setpoint = MOP setpoint
52 Cmd = USS on RS485, Setpoint = Analog setpoint
53 Cmd = USS on RS485, Setpoint = Fixed frequency
54 Cmd = USS on RS485, Setpoint = USS on RS232 (reserved)
55 Cmd = USS on RS485, Setpoint = USS on RS485
57 Cmd = USS on RS485, Setpoint = Analog setpoint 2
Dependency: P0719 has higher priority than P0700 and P1000.
If set to a value other than 0 (i.e. BICO parameter is not the setpoint source), P0844 / P0848 (first source
of OFF2 / OFF3) are not effective; instead, P0845 / P0849 (second source of OFF2 / OFF3) apply and the
OFF commands are obtained via the particular source defined.
BICO connections made previously remain unchanged.
Notice: Particularly useful when e.g. changing command source temporarily from P0700 = 2.
Settings in P0719 (contrary to P0700 settings) do not reset the digital inputs (P0701, P0702, ...)
r0720 Number of digital inputs - - - - - U16 3
Displays number of digital inputs.
r0722.0...12 CO / BO: Digital input
values
- - - - - U16 2
Displays status of digital inputs.
