Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
164 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Dependency: P1060 and P1061 set up and down ramp times respectively for jogging. Rounding times (P1130 - P1133),
rounding type (P1134) and P2167 will also have influence on the JOG ramp.
P1059[0...2] JOG frequency left [Hz] 0.00 -
599.00
5.00 U, T - DDS Float 2
While JOG left is selected, this parameter determines the frequency at which the inverter will run.
Dependency: P1060 and P1061 set up and down ramp times respectively for jogging.
P1060[0...2] JOG ramp-up time [s] 0.00 -
650.00
10.00 U, T - DDS Float 2
Sets jog ramp-up time. This is the time used while jogging is active.
Dependency: See also P3350, P3353.
Notice: Ramp times will be used as follows:
• P1060 / P1061 : JOG mode is active
• P1120 / P1121 : Normal mode (ON / OFF) is active
• P1060 / P1061 : Normal mode (ON / OFF) and P1124 is active
The rounding of P1130 - P1133 also applies to the JOG ramping.
Note: If the SuperTorque function is enabled, the inverter will initially ramp using the value in P3353.
P1061[0...2] JOG ramp-down time [s] 0.00 -
650.00
10.00 U, T - DDS Float 2
Sets ramp-down time. This is the time used while jogging is active.
Dependency: See also P3350, P3353.
Note: See P1060
P1070[0...2] CI: Main setpoint - 1050[0] T - CDS U32 /
I32
3
Defines source of main setpoint.
P1071[0...2] CI: Main setpoint scaling - 1 T 4000H CDS U32 /
I16
3
Defines source of the main setpoint scaling.
P1074[0...2] BI: Disable additional
setpoint
- 0 U, T - CDS U32 /
Bin
3
Disables additional setpoint.
P1075[0...2] CI: Additional setpoint - 0 T - CDS U32 /
I32
3
Defines source of the additional setpoint (to be added to main setpoint).
P1076[0...2] CI: Additional setpoint
scaling
- [0] 1 [1] 0
[2] 1
T 4000H CDS U32 /
I16
3
Defines source of scaling for additional setpoint (to be added to main setpoint).
r1078 CO: Total frequency
setpoint [Hz]
- - - - - Float 3
Displays sum of main and additional setpoints.
r1079 CO: Selected frequency
setpoint [Hz]
- - - - - Float 3
Displays selected frequency setpoint. Following frequency setpoints are displayed:
• r1078 Total frequency setpoint
• P1058 JOG frequency right
• P1059 JOG frequency left
Dependency: P1055 (BI: Enable JOG right) or P1056 (BI: Enable JOG left) define command source of JOG right or JOG
left respectively.
