Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
193
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Dependency: See P2012
Note: To enable the external fault (r2037 bit 13) facility via USS, the following parameters must be set:
• P2012 = 4
• P2106 = 1
r2067.0...12 CO / BO: Digital input
values status
- - - - - U16 3
Displays status of digital inputs.
Bit Signal name 1 signal 0 signal
00 Digital input 1 Yes No
01 Digital input 2 Yes No
02 Digital input 3 Yes No
03 Digital input 4 Yes No
11 Digital input AI1 Yes No
12 Digital input AI2 Yes No
Note: This is used for BICO connection without software intervention.
P2100[0...2] Alarm number selection 0 - 65535 0 T - - U16 3
Selects up to 3 faults or warnings for non-default reactions.
Example: If, for example, an OFF3 is to be carried out instead of an OFF2 for a fault, the fault number has to be
entered in P2100 and the desired reaction selected in P2101 (in this case (OFF3) P2101 = 3).
Index: [0] Fault Number 1
[1] Fault Number 2
[2] Fault Number 3
Note: All fault codes have a default reaction to OFF2.
Some fault codes caused by hardware trips (e.g. overcurrent) cannot be changed from the default
reactions.
P2101[0...2] Stop reaction value 0 - 3 0 T - - U16 3
Sets inverter stop reaction values for faults selected by P2100 (alarm number selection). This indexed
parameter specifies the special reaction to the faults / warnings defined in P2100 indices 0 to 2.
0 No reaction, no display
1 OFF1 stop reaction
2 OFF2 stop reaction
3 OFF3 stop reaction
Index: [0] Stop reaction value 1
[1] Stop reaction value 2
[2] Stop reaction value 3
Note: Settings 1 - 3 are only available for fault codes.
Index 0 (P2101) refers to fault / warning in index 0 (P2100).
P2103[0...2] BI: 1. Faults
acknowledgement
- 722.2 T - CDS U32 /
Bin
3
Defines first source of fault acknowledgement.
P2104[0...2] BI: 2. Faults
acknowledgement
- 0 T - CDS U32 /
Bin
3
Selects second source of fault acknowledgement.
P2106[0...2] BI: External fault - 1 T - CDS U32 /
Bin
3
Selects source of external faults.
