Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
192 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Index: [0] USS / MODBUS on RS485
[1] USS on RS232 (reserved)
Note: The state of the telegram information on RS485 is reported regardless of the protocol set in P2023.
r2025[0...1] USS / MODBUS rejected
telegrams
- - - - - U16 3
Displays number of USS / MODBUS telegrams rejected.
Index: See r2024
Note: See r2024
r2026[0...1] USS / MODBUS
character frame error
- - - - - U16 3
Displays number of USS / MODBUS character frame errors.
Index: See r2024
Note: See r2024
r2027[0...1] USS / MODBUS overrun
error
- - - - - U16 3
Displays number of USS / MODBUS with overrun error.
Index: See r2024
Note: See r2024
r2028[0...1] USS / MODBUS parity
error
- - - - - U16 3
Displays number of USS / MODBUS telegrams with parity error.
Index: See r2024
Note: See r2024
r2029[0...1] USS start not identified - - - - - U16 3
Displays number of USS telegrams with unidentified start.
Index: See r2024
Note: Not used on MODBUS.
r2030[0...1] USS / MODBUS BCC /
CRC error
- - - - - U16 3
Displays number of USS / MODBUS telegrams with BCC / CRC error.
Index: See r2024
Note: See r2024
r2031[0...1] USS / MODBUS length
error
- - - - - U16 3
Displays number of USS / MODBUS telegrams with incorrect length.
Index: See r2024
Note: See r2024
r2036.0...15 BO: CtrlWrd1 from USS /
MODBUS on RS485
- - - - - U16 3
Displays control word 1 from USS / MODBUS on RS485 (i.e. word 1 within USS / MODBUS = PZD1). See
r0054 for the bit field description.
Dependency: See P2012
r2037.0...15 BO: CtrlWrd2 from USS
on RS485 (USS)
- - - - - U16 3
Displays control word 2 from USS on RS485 (i.e. word 4 within USS = PZD4). See r0055 for the bit field
description.
