Siemens SINAMICS V20 Series User Manual

Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
201
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P2213[0...2] Fixed PID setpoint 13
[%]
-200.00 -
200.00
0.00 U, T - DDS Float 2
Defines fixed PID setpoint 13.
Note: See P2201
P2214[0...2] Fixed PID setpoint 14
[%]
-200.00 -
200.00
0.00 U, T - DDS Float 2
Defines fixed PID setpoint 14.
Note: See P2201
P2215[0...2] Fixed PID setpoint 15
[%]
-200.00 -
200.00
0.00 U, T - DDS Float 2
Defines fixed PID setpoint 15.
Note: See P2201
P2216[0...2] Fixed PID setpoint mode 1 - 2 1 T - DDS U16 2
Fixed frequencies for PID setpoint can be selected in two different modes. P2216 defines the mode.
1 Direct selection
2 Binary selection
P2220[0...2] BI: Fixed PID setpoint
select bit 0
- 722.3 T - CDS U32 /
Bin
3
Defines command source of fixed PID setpoint selection bit 0.
P2221[0...2] BI: Fixed PID setpoint
select bit 1
- 722.4 T - CDS U32 /
Bin
3
Defines command source of fixed PID setpoint selection bit 1.
P2222[0...2] BI: Fixed PID setpoint
select bit 2
- 722.5 T - CDS U32 /
Bin
3
Defines command source of fixed PID setpoint selection bit 2.
P2223[0...2] BI: Fixed PID setpoint
select bit 3
- 722.6 T - CDS U32 /
Bin
3
Defines command source of fixed PID setpoint selection bit 3.
r2224 CO: Actual fixed PID
setpoint [%]
- - - - - Float 2
Displays total output of PID fixed setpoint selection.
Note: r2224 = 100 % corresponds to 4000 hex.
r2225.0 BO: PID fixed frequency
status
- - - - - U16 3
Displays the status of PID fixed frequencies.
Bit Signal name 1 signal 0 signal
00 Status of FF Yes No
P2231[0...2] PID-MOP mode - 0 U, T - DDS U16 2
PID-MOP mode specification
Bit Signal name 1 signal 0 signal
00 Setpoint store active Yes No
01 No On-state for MOP necessary Yes No
Note: Defines the operation mode of the motorized potentiometer. See P2240.
P2232 Inhibit reverse direction
of PID-MOP
0 - 1 1 T - - U16 2
Inhibits reverse setpoint selection of the PID-MOP.
