Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
212 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
r2379.0...1 CO / BO: Motor staging
status word
- - - - - U16 3
Output word from the motor staging feature that allows external connections to be made.
Bit Signal name 1 signal 0 signal
00 Start motor 1 Yes No
01 Start motor 2 Yes No
P2380[0...2] Motor staging hours run
[h]
0.0 -
42949672
0.0
0.0 U, T - - Float 3
Displays hours run for external motors. To reset the running hours, set the value to zero, any other value is
ignored.
Example: P2380 = 0.1 ==> 6 min
60 min = 1 h
Index: [0] Motor 1 hrs run
[1] Motor 2 hrs run
[2] Not used
P2800 Enable FFBs 0 - 1 0 U, T - - U16 3
Free function blocks (FFB) are enabled in two steps:
1. P2800 enables all free function blocks (P2800 = 1).
2. P2801 and P2802 respectively, enable each free function block individually. Additionally fast free
function blocks can be enabled via P2803 = 1.
0 Disable
1 Enable
Dependency: All active function blocks will be calculated in every 128 ms, fast free function blocks in every 8 ms.
P2801[0...16] Activate FFBs 0 - 6 0 U, T - - U16 3
P2801 and P2802 respectively, enable each free function block individually (P2801[x] > 0 or P2802[x] > 0).
In addition, P2801 and P2802 determine the chronological order of each function block by setting the level
in which the free function block will work.
The following table shows that the priority decreases from right to left and from top to bottom.
)DVW))%V
3ULRULW\
ORZ
ORZ
KLJK
3ULRULW\
/HYHO
/HYHO
/HYHO
/HYHO
/HYHO
/HYHO
,QDFWLYH
3>@7LPHU
3>@7LPHU
3>@7LPHU
3>@7LPHU
3
3>@',9
3>@$1'
3>@$1'
3>@$1'
3>@25
3>@25
3>@25
3>@;25
3>@;25
3>@;25
3>@127
3>@127
3>@127
3>@'))
3>@'))
3>@56))
3>@56))
3>@56))
3>@$''
3>@$''
3>@68%
3>@68%
3>@08/
3>@08/
3>@',9
3>@&03
3>@&03
0 Not Active
