Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
213
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
1 Level 1
2 Level 2
... ...
6 Level 6
Example: P2801[3] = 2, P2801[4] = 2, P2802[3] = 3, P2802[4] = 2
FFBs will be calculated in following order: P2802[3], P2801[3] , P2801[4], P2802[4]
Index: [0] Enable AND 1
[1] Enable AND 2
[2] Enable AND 3
[3] Enable OR 1
[4] Enable OR 2
[5] Enable OR 3
[6] Enable XOR 1
[7] Enable XOR 2
[8] Enable XOR 3
[9] Enable NOT 1
[10] Enable NOT 2
[11] Enable NOT 3
[12] Enable D-FF 1
[13] Enable D-FF 2
[14] Enable RS-FF 1
[15] Enable RS-FF 2
[16] Enable RS-FF 3
Dependency: Set P2800 to 1 to enable function blocks.
All active function blocks will be calculated in every 128 ms, if set to level 1 ... 3. Fast free function blocks
(level 4 ... 6) will be calculated in every 8 ms.
P2802[0...13] Activate FFBs 0 - 3 0 U, T - - U16 3
Enables free function blocks (FFB) and determines the chronological order of each function block. See
P2801.
0 Not Active
1 Level 1
2 Level 2
3 Level 3
Index: [0] Enable timer 1
[1] Enable timer 2
[2] Enable timer 3
[3] Enable timer 4
[4] Enable ADD 1
[5] Enable ADD 2
[6] Enable SUB 1
[7] Enable SUB 2
[8] Enable MUL 1
[9] Enable MUL 2
[10] Enable DIV 1
[11] Enable DIV 2
