Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
220 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P2850 Delay time of timer 1 [s] 0.0 -
9999.9
0.0 U, T - - Float 3
Defines delay time of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are r2852, r2853.
Dependency: See P2849
P2851 Mode timer 1 0 - 13 0 U, T - - U16 3
Selects mode of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are r2852, r2853.
0 ON delay (seconds)
1 OFF delay (seconds)
2 ON / OFF delay (seconds)
3 Pulse generator (seconds)
10 ON delay (minutes)
11 OFF delay (minutes)
12 ON / OFF delay (minutes)
13 Pulse generator (minutes)
Dependency: See P2849
r2852.0 BO: Timer 1 - - - - - U16 3
Displays output of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are r2852, r2853. See
r2811 for the bit field description.
Dependency: See P2849
r2853.0 BO: Nout timer 1 - - - - - U16 3
Displays Not-output of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are r2852, r2853.
See r2811 for the bit field description.
Dependency: See P2849
P2854 BI: Timer 2 - 0 U, T - - U32 /
Bin
3
Define input signal of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are r2857, r2858.
Dependency: P2802[1] assigns the timer to the processing sequence.
P2855 Delay time of timer 2 [s] 0.0 -
9999.9
0.0 U, T - - Float 3
Defines delay time of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are r2857, r2858.
Dependency: See P2854
P2856 Mode timer 2 0 - 13 0 U, T - - U16 3
Selects mode of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are r2857, r2858.
See P2851 for value description.
Dependency: See P2854
r2857.0 BO: Timer 2 - - - - - U16 3
Displays output of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are r2857, r2858. See
r2811 for the bit field description.
Dependency: See P2854
r2858.0 BO: Nout timer 2 - - - - - U16 3
Displays Not-output of timer 2 P2854, P2855, P2856 are the inputs of the timer, outputs are r2857, r2858.
See r2811 for the bit field description.
Dependency: See P2854
P2859 BI: Timer 3 - 0 U, T - - U32 /
Bin
3
Define input signal of timer 3. P2859, P2860, P2861 are the inputs of the timer, outputs are r2862, r2863.
