Electrical installation
4.2 Terminal description
SINAMICS V20 Inverter
26 Operating Instructions, 07/2012, A5E03728167
No. Terminal
marking
Description
Response time: 4 ms ± 4 ms
Pulse train input: No
13 24V 24 V output (tolerance - 15 % ... + 20 %) referred to 0 V, maximum 50 mA, non-
isolated
14 0V Overall reference potential for digital inputs
Mode: Normally open voltage-free terminals, polarised
Isolation to control circuit: 100 V DC (functional low voltage)
Maximum voltage across
terminals:
± 35 V
Maximum load current: 100 mA
Digital
output
(transistor)
15
16
DO1 +
DO1 -
Response time: 4 ms ± 4 ms
Mode: Change-over voltage-free terminals, unploarised
Isolation to control circuit: 4 kV (230 V mains)
Maximum voltage across
terminals:
240 V AC / 30 V DC + 10 %
Maximum load current: 0.5 A @ 250 V AC, resistive
0.5 A @ 30 V DC, resistive
Digital
output
(relay)
17
18
19
DO2 NC
DO2 NO
DO2 C
Response time: Open: 7 ms ± 7 ms
Close: 10 ms ± 9 ms
WARNING
I/O Terminals 1… 16 are safety extra low voltage (SELV) and must only be connected to
low voltage supplies.
Permissible I/O terminal cable cross sections
Cable type Permissible cable cross section
Solid or stranded cable 0.5 ... 1.5 mm
2
Ferrule without insulating sleeve 0.5 ... 1.0 mm
2
Ferrule with insulating sleeve 0.5 mm
2
Expansion port
The expansion port is designed for connecting the inverter to the external option module -
BOP Interface Module or Parameter Loader, in order to realize the following functions:
● Operating the inverter from the external BOP
● Cloning parameters between the inverter and a standard MMC / SD card
● Powering the inverter from the Parameter Loader, when mains power is not available
For more information about these two option modules, refer to the topics "
Parameter Loader
(Page
247)" and "External BOP and BOP Interface Module (Page 251)".
