PLC Subroutines Manual
6FC5397-0FP40-0BA0, 08/2013
19
Select the TCP/IP pointed to the Ethernet card of your PC, and then click the
button.
You can find the name of your Ethernet card under "Start" > "Settings" > "Network
connections" on your PC.
3. On the left side of the communication setting window, enter the IP address for the
corresponding SINUMERIK 808D ADVANCED control, which is previously displayed in the link
setting dialog on the control, as shown below.
4. Double click this icon on the right side of the communication setting window to establish a
connection to the specified IP address.
● Before configuring communications in the PLC Programming Tool, make sure the connection must be already enabled
on the control.
● Ensure that the IP address of your PC and the IP address of the control exist in the same network segment.
