Siemens SINUMERIK 808D ADVANCED T User Manual

PLC Subroutines Manual
6FC5397-0FP40-0BA0, 08/2013
61
3.30
Subroutine 58 (MM_MAIN)
Purpose
To use subroutine 58, you must have licensed the optional Manual Machine Plus function for the SINUMERIK 808D
ADVANCED T (Turning). The subroutines 46, 58 and 59 must be used together. This subroutine is used to control the
manual machine function after the manual machine interface is activated.
Local variable definition
Table 3-38 Inputs
Name
Type
Description
TK_X_P BOOL Forward on axis X
TK_X_M BOOL Backward on axis X
TK_Z_P BOOL Forward on axis Z
TK_Z_M BOOL Backward on axis Z
RAPID BOOL Rapid feed
SP_CW BOOL Clockwise rotation of the spindle
SP_CCW BOOL Counter-clockwise rotation of the spindle
SP_STOP BOOL Spindle stop
NC_START BOOL NC start
NC_STOP BOOL NC stop
AUTO_ENABLE BOOL AUTO mode allowed
MDA_ENABLE BOOL MDA mode allowed
ROV BOOL Rapid rate
Table 3-39 Outputs
Name
Type
Description
AL_03 BOOL Not approaching the reference point on axis X
AL_04 BOOL Not approaching the reference point on axis Z
AL_09 BOOL Incorrect start in the spindle direction
AL_11 BOOL JOG program timeout
AL_12 BOOL Spindle rate not 100%
AL_13 BOOL Spindle not being started
AL_14 BOOL Feed rate 0%
AL_16 BOOL Spindle direction change in a thread not allowed
Assigned global variables
Byte
Signal
Byte 7
Byte 6
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0
MB170 HMI<->MM Request
for MM
HMI
startup
MM HMI
enabled
MM HMI
started
MB171 HMI<->MM
MB172 HMI<->MM
MB173 HMI<->MM
