Siemens SINUMERIK 808D ADVANCED T User Manual

PLC Subroutines Manual
68 6FC5397-0FP40-0BA0, 08/2013
Alarm No.
Interface Address
Alarm Description
From SBR
700023 DB1600.DBX2.7 Programmed tool number > max. turret on turret
number
SBR52: Turret2_BIN_T
SBR53: Turret3_CODE_T
700024 DB1600.DBX3.0 Max. tool number setting error
700025 DB1600.DBX3.1 No position signals from turret
700026 DB1600.DBX3.2 Not able to find expected tool in monitor time
700027 DB1600.DBX3.3 Approach reference point again after rotation
monitoring
SBR40: AXIS_CTL
700028 DB1600.DBX3.4 Tool is not locked SBR53: Turret3_CODE_T
700029 DB1600.DBX3.5 Reminding information for 1st service plan SBR48: ServPlan
700030 DB1600.DBX3.6 Alarm for 1st service plan
700031 DB1600.DBX3.7 Magazine not in spindle position or original
position
SBR60: Disk_MGZ_M
700032 DB1600.DBX4.0 Magazine in spindle position and original
position
SBR60: Disk_MGZ_M
700033 DB1600.DBX4.1 Magazine turn key when magazine or spindle
not ready
SBR60: Disk_MGZ_M
700034 DB1600.DBX4.2 Block search, tool in spindle <> programmed
tool
SBR60: Disk_MGZ_M
700035 DB1600.DBX4.3 Spindle not reach tool-release pos. in time SBR60: Disk_MGZ_M
700036 DB1600.DBX4.4 Spindle not reach tool-lock pos. in time SBR60: Disk_MGZ_M
700049 DB1600.DBX6.1 Reference point X-axis not reached SBR58: MM_MAIN
700050 DB1600.DBX6.2 Reference point Z-axis not reached SBR58: MM_MAIN
700051 DB1600.DBX6.3 Wrong spindle direction started SBR58: MM_MAIN
700052 DB1600.DBX6.4 Watchdog timer JOG-program SBR58: MM_MAIN
700053 DB1600.DBX6.5 Spindle override not 100% SBR58: MM_MAIN
700054 DB1600.DBX6.6 Spindle is not started SBR58: MM_MAIN
700055 DB1600.DBX6.7 Feed override = 0% SBR58: MM_MAIN
700056 DB1600.DBX7.0 Change of spindle direction not possible in
thread
SBR58: MM_MAIN
700059 DB1600.DBX7.3 Safe door not closed, NC start not possible SBR22:
AUX_SAFE_DOOR
700060 DB1600.DBX7.4 PRT/AFL change not possible: channel not
reset
SBR37: MCP_NCK
5
PLC sample applications
5.1
PLC sample application (turning)
This sample application is applicable to machines with the following configurations:
● Two axes: axes X and Z, with a hardware limit switch respectively in the positive and negative directions of each axis
● An analog spindle: SP
● HALL effect device turret with six-working stations
● PLC-controlled timely and quantitatively lubrication system
● PLC-controlled cooling system
