Typical turning program
Turning Part 2: Programming (Siemens instructions)
Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
203
,)
T2 D1
G96 S250 M03 M08
CYCLE95( "CON2:CON2_E", 0.50000, , ,0.20000, 0.40000, 0.30000, 0.20000, 9, , ,)
M30
CON1:
;#7__DlgK contour definition begin - Don't change!;*GP*;*RO*;*HD*
G18 G90 DIAMON;*GP*
G0 Z0 X16 ;*GP*
G1 Z-2 X20 ;*GP*
Z-20 ;*GP*
X35 RND=2 ;*GP*
Z-50 RND=2 ;*GP*
X55 CHR=2 ;*GP*
Z-70 ;*GP*
;CON,V64,2,0.0000,6,6,MST:1,2,AX:Z,X,K,I;*GP*;*RO*;*HD*
;S,EX:0,EY:16,ASE:0;*GP*;*RO*;*HD*
;LA,EX:-2,EY:20;*GP*;*RO*;*HD*
;LL,EX:-20;*GP*;*RO*;*HD*
;LU,EY:35;*GP*;*RO*;*HD*
;R,RROUND:2;*GP*;*RO*;*HD*
;LL,DEX:-30;*GP*;*RO*;*HD*
;R,RROUND:2;*GP*;*RO*;*HD*
;LU,EY:55;*GP*;*RO*;*HD*
;F,LFASE:2;*GP*;*RO*;*HD*
;LL,EX:-70;*GP*;*RO*;*HD*
;#End contour definition end - Don't change!;*GP*;*RO*;*HD*
CON1_E:
;*************CONTOUR************
CON2:
;#7__DlgK contour definition begin - Don't change!;*GP*;*RO*;*HD*
G18 G90 DIAMON;*GP*
G0 Z-22.5 X35 ;*GP*
G2 Z-47.5 K=AC(-35) I=AC(89.544) ;*GP*
G1 Z-49.5 ;*GP*
;CON,V64,2,0.0000,1,1,MST:1,2,AX:Z,X,K,I;*GP*;*RO*;*HD*
;S,EX:-22.5,EY:35,ASE:0;*GP*;*RO*;*HD*
;ACW,DIA:0/235,DEX:-25,DEY:0,RAD:30;*GP*;*RO*;*HD*
;LL,DEX:-2;*GP*;*RO*;*HD*
;#End contour definition end - Don't change!;*GP*;*RO*;*HD*
CON2_E:;************* CONTOUR ENDS ************
